Feature:
Main feature:
Height adjustable range 450mm for c-arm, longitudinal movement 530mm, with emergency power, build-in waist bridge, table V position 100°, anti-V position 220°, two control panels,suitable for x-ray and c-arm

Specification:
Overall Dimension of table:2100mm*500mm*(700-1150)(L*W*H)
Dimension of section:
1)Head Section:250×500mm
2)Back Section:465×500mm
3)Kidney Bridge:75×500mm
4)Seat section:630×500mm
5)Leg Section:600×240mm
Range of movements:
1)Reversed Trendelenburg:≥30°
2)Trendelenburg:≥25°
3)Lateral Tilt:≥25°
4)Backward and Forward Movements:≥530mm
5)Head Section Raised and lowered from the horizontal:≥45°, ≥90°
6)Back Section Raised and Lowered from the horizontal:≥75°, ≥30°
7)Leg Section Lowered from the horizontal:≥90°
8)Leg section opened:≥90°
9)Kidney Bridge Elevated (When optional):≥80mm
10)Level reset zero (When optional):±2°
11)Lifting speed:4~16mm/s
12)safe working load:150kg
13)Device safety sort:  I  B
14)Ingress Protection:IPX4
15)Power:(AC)220V,50Hz
16)Internal electric source:(DC)24V
17)Battery capacity ≥ 2.4AH
