Feature:
Main feature:
Extra low design 680mm min height,longitudinal movement 250mm,with emergency power,suitable for x-ray and c-arm

Dimension of table top:
Overall Dimension of table: 2125*500*680-930mm
Dimension of section:
Head Section:250×500mm;Back Section:465×500mm;Waist Section:75×500mm;Seat section:550×500mm; Leg Section:600×240mm
Range of movements:
1)Reversed Trendelenburg≥20°rendelenburg≥15°
2)Lateral Til≥15°
3)Backward and Forward Movements≥250mm
4)Adjustment of sections:
5)Head Section Raised  from the horizontal:≥45°
6)Head Section lowered from the horizonal: ≥90°
7)Back Section Raised from the horizontal≥75°
8)Back Section Raised from the horizontal: ≥30°
9)Section Lowered from the horizontal:≥90°
10)Leg section opened:≥90°
11)Waist bridge  rise(When optional)≥80mm
13)Lifting speed: 4~16mm/s
14)safe working load135kg
15)Device safety sortI     B
16)Ingress Protection:IPX4
17)Power:(AC)220V,50Hz
18)Battery capacity is 14 AH  Battery capacity ≥ 2.4AH
